Alternateur A.R.K7F

A.R.K7F Alternateur – Alternateur Heavy-Duty Sans Balais à Excitation PMG Haute Efficacité

L’A.R.K7F est un alternateur synchrone triphasé sans balais, heavy-duty, équipé d’une excitation PMG et d’un AVR MX321 pour une régulation de tension très précise et une excellente réponse dynamique. Avec ±1 % de régulation, un THD < 5 % et un rendement jusqu’à 96,4 %, il fournit une puissance propre, stable et hautement efficace pour les systèmes industriels, de location, télécom et standby. Construit avec classe H, IP23 et roulements graissés à vie, il est conçu pour une fiabilité maximale dans les environnements les plus exigeants.

Demander un devis

Puissance Principale (kVA / kW)

Puissance Standby (kVA / kW)

Vitesse (r.p.m)

Tension Standard (V)

Facteur puissance (Cos Phi)

Electrical Performance

  • Type: Three-phase, brushless synchronous alternator with PMG excitation

  • Frequency: 50 / 60 Hz

  • Power Factor: 0.8

  • Voltage Range: 380/220V – 480/277V (configurable in star, delta, or parallel star)

  • Voltage Regulation: ±1.0%

  • Total Harmonic Distortion (THD): <5% (balanced linear load), <1.5% (no-load)

  • Sustained Short Circuit Current: >300% rated current for 10 seconds

  • Efficiency: Up to 96.4% depending on frequency and load

  • Overload Capacity: 110% for one hour in a six-hour cycle

  • Telephone Harmonic Factor (THF): <2%

  • Telephone Interference Factor (TIF): <50

  • Short Circuit Ratio (1/Xd): 0.19 typical

  • Power Ratings (Winding 311):

    • 50 Hz: 1100–1375 kVA (Efficiency 96.0–96.4%)

    • 60 Hz: 1250–1650 kVA (Efficiency 95.7–96.2%)

  • Reactances (Per Unit at Rated kVA):

    • Xd (Synchronous): 2.26–3.23

    • X’d (Transient): 0.18–0.25

    • X’’d (Subtransient): 0.07–0.13

    • Xq (Quadrature): 2.04–3.16

    • X’’q (Quadrature Subtransient): 0.22–0.27

    • X₂ (Negative Sequence): 0.14–0.16

    • X₀ (Zero Sequence): 0.04–0.06

    • Leakage Reactance (XL): 0.03

  • Time Constants:

    • Transient (T’d): 0.3 s

    • Subtransient (T’’d): 0.03 s

    • Armature (Ta): 0.06 s

    • Open Circuit Field (T’do): 3.16 s

Construction & Design

  • Insulation Class: H (125°C rise at 40°C ambient)

  • Protection: IP23 (optional IP44 with 5–10% power reduction)

  • Cooling: Self-ventilated air cooling

    • 50 Hz: 2.64 m³/s (5600 cfm)

    • 60 Hz: 3.17 m³/s (6720 cfm)

  • Frame: Rigid steel structure with cast aluminum front and rear covers

  • Stator: Double-layer winding, 2/3 pitch design eliminates triple harmonics

  • Rotor: Damped rotor dynamically balanced to BS6861 standards

  • Bearings:

    • Drive End: 6319 (sealed-for-life ball bearing)

    • Non-Drive End: 6228 (sealed-for-life ball bearing)

  • Overspeed Capability: 120% of rated speed (2250 rpm)

  • Leads: 12 reconnectable leads (star, delta, or parallel star)

  • Inertia (WR²): 36.49–37.49 kg·m²

  • Winding Resistance:

    • Stator: 0.00126 Ω/phase (22°C, star connection)

    • Rotor: 1.41 Ω (22°C)

Dimensions & Weight

  • Rotor Weight: 1181–1244 kg

  • Stator Weight: 1541 kg

  • Complete Alternator Weight: 2982–3130 kg

  • Shipping Weight (Crated): 3054–3070 kg

  • Packing Dimensions: 194 × 105 × 154 cm

Regulation & Control

  • Excitation System: PMG excitation with brushless AVR

  • AVR Models: MX321 (standard), optional MX341, SX440, SX460, AS440

  • Voltage Regulation Accuracy: ±1.0%

  • Parallel Operation: Supported (AVR-dependent)

  • Protection Features:

    • Stator winding and bearing overheat protection

    • Anti-condensation heater (optional)

    • Low-speed voltage drop protection

  • RFI Suppression: Complies with BS EN 61000-6-2 & BS EN 61000-6-4, VDE 0875G/N

  • Standards Compliance: IEC60034, GB755, BS5000, NEMA MG1-22, CSA C22.2-100, AS1359

  • Certification: ISO9001 Quality Management System

Environmental Parameters

  • Operating Temperature: –15°C to +40°C

  • Relative Humidity: Up to 95% (non-condensing)

  • Altitude: Up to 1000 m without derating

  • Cooling Air Requirement: 2.64–3.17 m³/s depending on frequency

  • Noise & Vibration: Dynamically balanced per BS6861 mechanical standards

Performance Summary

  • Efficiency Range: 95.7–96.4%

  • Voltage Dip (Transient Load): ≤25% at 0.8 PF

  • Recovery Time: <0.5 seconds

  • Locked Rotor Motor Starting: >300% rated current

  • Applications: Prime power, standby, rental, telecom, mobile, railway, lighting tower, and refrigeration generator systems
